Self lubricating plug valve- class 150

Product Description

BODY	ASTM A 216 Gr WCB
PLUG	ASTM A 216 Gr WCB
MFG STD	GENERALLY CONFORMING TO MSS SP 78 \| BS 5158
INSP & TEST STD	GENERALLY CONFORMING TO MSS SP 78 \| BS 6755
MAX. C.W.P	150 Psig (10.54 Kg/Cm ²)
ENDS	FLANGED TO ASME B 16.5 RF (150#)
HYD-TEST PRESSURE	BODY :225 Psig (16 Kg/Cm ²)
	SEAT :165 Psig (11.5 Kg/Cm ²)
SIZE RANGE	15 MM TO 350 MM FLANGED END
